HL50
Engine model : LR4A3-23/LR4B5-23
Max Power : 42kW
Engine model : LR4A3-23/LR4B5-23
Max Power : 42kW
| ITEMS | PARAMETERS |
|---|---|
| Model | PMHL50 |
| Overall dimensions (L × W × H) | 4850 × 2090 × 2850mm |
| Welder positions | 2 |
| Tractor | YTO X700 |
| Drive mode | 4 × 2 |
| Wheelbase | 2342mm |
| Front wheel distance | 1400mm – 1900mm |
| Rear wheel distance | 1500mm – 2100mm |
| Ground clearance | 430mm |
| Max gradeability | 35° |
| Traction | 19.58kN |
| Engine | |
| Model | LR4A3-23 / LR4B5-23 |
| Rated power | 51.5kW |
| Rated rotary speed | 2300r/min |
| Generator | |
| Model | Stanford UCI224E / Faraday FD2C2-4 |
| Max output power | 42kW |
| Rated voltage | 380V / 220V |
| Speed | |
| Forward | 1.92 – 31.72km/h |
| Backward | 5.00 – 15.01km/h |
