Arabian Equipment The Pneumatic Wedge Mandrel is used to develop specifically to meet the bending requirements of heavy-wall and high - yield grade pipe.The PWM applies powerful radial support to the inner walls, yet remains flexible lengthwise to bend with the pipe. It is positioned and controlled manually within the pipe by a reach rod. It is particularly successful in providing a smooth bend with no 'out-of-round'.
SALIENT FEATURES |
|
Polyurethane wheels for all sizes.
|
| MODEL | PIPE SIZE INCH | LENGTH [MM] | WIDTH [MM] | HEIGHT [MM] | WEIGHT [KG] | NO. OF CYL | HP | QTY | TYPE |
|---|---|---|---|---|---|---|---|---|---|
| PC 10 - 12” | 10 - 12" | 1625 | 254 | 292 | 136 | 6 | NIL | NIL | Non-Self propelled |
| PC 12 - 14” | 12 - 14" | 2286 | 305 | 343 | 161 | 6 | NIL | NIL | Non-Self propelled |
| PC 16 - 18” | 16 - 18" | 2620 | 406 | 445 | 240 | 8 | 1 | 1 | Self propelled |
| PC 20 - 22” | 20 - 22" | 2680 | 470 | 508 | 315 | 8 | 1 | 1 | Self propelled |
| PC 24 - 26” | 24 - 26" | 2880 | 610 | 648 | 500 | 10 | 1 | 1 | Self propelled |
| PC 26 - 28” | 26 - 28" | 3130 | 700 | 720 | 500 | 12 | 3 | 1 | Self propelled |
| PC 28 - 30” | 28 - 30" | 2880 | 710 | 750 | 510 | 12 | 3 | 1 | Self propelled |
| PC 30 - 32” | 30 - 32" | 3160 | 762 | 800 | 625 | 16 | 3 | 1 | Self propelled |
| PC 34 - 36” | 34 - 36" | 3400 | 910 | 910 | 820 | 20 | 3 | 1 | Self propelled |
| PC 36 - 38 | 36 - 38" | 3668 | 914 | 955 | 940 | 24 | 3 | 1 | Self propelled |
| PC 38 - 40" | 38 - 40" | 3668 | 920 | 970 | 1200 | 24 | 3 | 1 | Self propelled |
| PC 40 - 42” | 40 - 42" | 3658 | 1016 | 1055 | 1300 | 24 | 3 | 2 | Self propelled |
| PC 42 - 44” | 42 - 44" | 3970 | 1050 | 1055 | 1400 | 24 | 3 | 2 | Self propelled |
| PC 46 - 48” | 46 - 48" | 3850 | 1143 | 1180 | 1525 | 24 | 3 | 2 | Self propelled |
| PC 50 - 52” | 50 - 52" | 4000 | 1270 | 1308 | 2100 | 24 | 3 | 2 | Self propelled |
| PC 52 - 54" | 52 - 54" | 4572 | 1320 | 1360 | 2200 | 24 | 3 | 2 | Self propelled |
| PC 54 - 56” | 54 - 56" | 4000 | 1372 | 1410 | 2400 | 24 | 3 | 2 | Self propelled |
| PC 58 - 60” | 58 - 60" | 4600 | 1473 | 1525 | 2702 | 24 | 3 | 2 | Self propelled |
